Specification in details

1.5 Ton

Basic Specifications

Model Name

MG AC 1.5 Ton Inverter -MGI-18K

Capacity (Ton)

1.5 Ton

Capacity (Btu/h)

18000

Cooling capacity (Watt)

5275 (1200-5800)

Rated power input  (watt)

1599

Rated Current (A)

7.6（1.4~12.0）

EER(W/W)

3.2

Heating capacity (Watt)

5422 (1200-5800)

Input watt

1694

EER(W/W)

3.2

Voltage range

155~265V

Frequency (Hz)

50 Hz

Rated  Airflow(M³/h)

810

Indoor Noise level(dB)

46

Outdoor Noise Lebel (dB)

Cooling Specifications

Refrigerant

R410a

Refrigerant amount (Kg)

1.3

Condenser Coil (material)

Copper (IGT)

Fin type

Hydrophilic

Evaporator Coil (material)

Copper (IGT)

Fin type

Golden Fin

Compressor Type

Rotary, Inverter

Operating Information

Temperature Control Range

16°C-31°C

Operation mode

Three type ( Turbo, ECO & Regular)

Turbo mode

Yes

Regular mode

Yes

ECO mode

Yes

Indoor fan speed

Low, Medium , High & Turbo

Display Type

LED Hidden Display

3D (Yes/No)

Yes

Swing Louver

Auto horizontal & Vartical swing

Anti-bacteria Filter (Yes/No)

Yes

Dust Filter (Yes/No)

Yes

Sleep Mode Timer (Yes/No)

Yes

Self/frost Cleaning

Yes

I feel mode

Yes

Packing Information

Indoor size (Dimensions-W*D*H) mm

920×306×195

Outdoor size (Dimensions-W*D*H) mm

853×349×602

Indoor Unit Packing dimensions (W*D*H) mm

990×382×266

Outdoor Unit Packing dimensions (W*D*H) mm

890×385×628

Indoor net Weight (kg)

10.16

Outdoor net weight (kg)

27.96

Warranty information

Compressor

10 years for residential

Spare parts

2 Years

Service

2 Years

Cleaning

1 Year

Free accessories

Copper pipe (Suction & discharge)

10 ft

Insulation

10 ft

Connecting wire

24 ft

Remote

1 Pcs

Warranty card & Manual

1 Pcs

Battery (AAA)

2 pcs
