Model Name | RSDC-24RTSI | ||
Type | Cooling only | ||
Control type | Remote | ||
Power supply | Ph-V-Hz | 208-230V~/50Hz/1P | |
Voltage Range | V | 165~265 | |
Cooling | Capacity | Btu/h | 24000(4090~24900) |
Capacity | W | 7035(1200~7300) | |
Rated power Input | W | 2314(300~2800) | |
Rated current | A | 10.7(2.5~13.5) | |
EER | W/W | 3.04 | |
Max power Input | W | 2800 | |
Max current | A | 13.5 | |
Indoor coil | a.Number of rows | 2 | |
b.Tube pitch(a)x row pitch(b) | mm | 21×12.7 | |
c.Fin spacing | mm | 1.4 | |
e.Tube outside dia.and type | mm | Φ7,innergroove tube | |
f.Coil length x height x width | mm | / | |
g.Number of circuits | 4 in 4 out | ||
Outdoor coil | a.Number of rows | 2 | |
b.Tube pitch(a)x row pitch(b) | mm | 19.5×11.6 | |
c.Fin spacing | mm | 1.2 | |
e.Tube outside dia.and type | mm | Φ5,innergroove tube | |
f.Coil length x height x width | mm | / | |
g.Number of circuits | 3 in 3 out | ||
Indoor unit | Dimension(W*D*H) | mm | 1010×315×220 |
Packing (W*D*H) | mm | 1096×390×297 | |
Net/Gross weight | Kg | 13/16 | |
Outdoor unit | Dimension(W*D*H) | mm | 853×349×602 |
Packing (W*D*H) | mm | 890×385×628 | |
Net/Gross weight | Kg | 30/35 | |
Pressure | High(DP) | MPa | 4.5 |
Low(SP) | MPa | 1.9 | |
Refrigerant | R410A/990g | ||
Ambient temperature | ℃ | -15~50 | |
Suitable area | m2 | 30~50 | |
Connecting Wiring |  | 4×0.75mm2 | |
Power supply cord | 3×1.5mm² | ||
 | 196 | ||
| Product Code |
33836 |
|---|---|
| Product Size |
No Product Size |
| Product Color |
No Product Color |
