Capacity (Cooling, Btu/hr)
21000Btu/hr
Capacity (Cooling, kW)
6.15kW
EER (Cooling, W/W)
3.16W/W
Net Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)
880*638*310mm
Specifications Detail
Capacity
Capacity (Cooling, Btu/hr)
21000 Btu/hr
Capacity (Cooling, Min - Max, Btu/hr)
5600 - 24200 Btu/hr
Capacity (Cooling, kW)
6.15 kW
Capacity (Cooling, Min - Max, kW)
1.64 - 7.09 kW
Energy Efficiency
EER (Cooling, W/W)
3.16 W/W
EER (Cooling, Btu/hW)
10.77 Btu/hW
ISEER
3.14
Energy Star Rating (Cooling)
1.5 Star
Noise Level
Noise Level (Indoor, High/Low, dBA)
44/28 dBA
Noise Level (Outdoor, High/Low, dBA)
53 dBA
Electrical Data
Power Source(Φ/V/Hz)
1 / 230 / 50
Power Consumption(Cooling, W)
1950 W
Operating Current(Cooling, A)
9.5 A
Physical specification
Gross Dimension (Indoor, WxHxD, ㎜*㎜*㎜)
1115*290*375 mm
Gross Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)
1023*724*413 mm
Net Dimension (Indoor, WxHxD, ㎜*㎜*㎜)
1055*299*215 mm
Net Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)
880*638*310 mm
Gross Weight (Indoor, kg)
13.20 kg
Gross Weight (Outdoor, kg)
43.00 kg
Net Weight (Indoor, kg)
11.60 kg
Net Weight (Outdoor, kg)
37.60 kg
Loading Quantity (20/40/40Hft without Pipe)
65/138/154
Technical Information
Piping Length (Max, m)
30 m
Piping Height (Max, m)
15 m
SVC Valve (Liquid (ODxL))
6.35
SVC Valve (Gas (ODxL))
15.88
Moisture Removal (l/hr)
2.2 l/hr
Air Circulation (Cooling, ㎥/min)
17.9 ㎥/min
Refrigerant (Type)
R410A
Refrigerant (Charging, kg)
1.40 kg
Refrigerant (Charging, tCO2e)
2.92 tCO2e
Low Ambient (Cooling, ℃)
16 ~ 46 ℃
Outdoor Unit (Compressor Type)
BLDC
Outdoor Unit (Anti-Corrosion Fin)
Yes
Air Flow
WindFree Cooling
Yes
Air Direction Control (Up/Down)
Auto
Air Direction Control (Left/Right)
Auto
Air Flow Control Step (Cool/Fan)
5/4
Air Purification
PM 1.0 Filter
No
4-in-1 Care Filter
No
Copper Anti-bacterial Filter
Yes
Auto Clean (Self Cleaning)
Yes
Convenience
SmartThings
Yes
AI Auto Cooling
Yes
Motion Detect Sensor
No
Freeze Wash
Yes
Filter Cleaning Indicatior
Yes
Indoor Temp. Display
Yes
Display On/Off
Yes
Beep On/Off
Yes
24-Hour Timer
Yes
Auto Changeover
No
Auto Restart
Yes
Operating Mode
Auto Mode
Yes
Fast Cool
Yes
Good Sleep
Yes
Eco Mode
Yes
Dehumidification
Yes
Fan Mode
Yes
Quiet
Yes
Smart
WiFi Embedded
Yes
App Connectivity
SmartThings App Support
Yes
